Public NotInheritable Class BuildingSceneLayer Inherits CompositeLayer Implements ArcGIS.Desktop.Core.IMetadataInfo, ILayerContainer, IMetadataSource, System.ComponentModel.INotifyPropertyChanged
public sealed class BuildingSceneLayer : CompositeLayer, ArcGIS.Desktop.Core.IMetadataInfo, ILayerContainer, IMetadataSource, System.ComponentModel.INotifyPropertyChanged
{
var bldgLayer = MapView.Active.Map.GetLayersAsFlattenedList().OfType<BuildingSceneLayer>().First();
var disciplines = new Dictionary<string, BuildingDisciplineSceneLayer>();
//A Building layer has two children - Overview and FullModel
//Overview is a FeatureSceneLayer
//Full Model is a BuildingDisciplineSceneLayer that contains the disciplines
var fullModel = bldgLayer.FindLayers("Full Model").First()
as BuildingDisciplineSceneLayer;
//collect information on the disciplines
var name = fullModel.Name;
var discipline = fullModel.GetDiscipline();
//etc
//TODO - use collected information
disciplines.Add(discipline, fullModel);
//Discipline layers are composite layers too
foreach (var childDiscipline in fullModel.Layers
.OfType<BuildingDisciplineSceneLayer>())
{
//Discipline layers can also contain FeatureSceneLayers that render the
//individual full model contents
var content_names = string.Join(", ", childDiscipline.Layers
.OfType<FeatureSceneLayer>().Select(fl => fl.Name));
// Recursively call this "function" to go deeper
}
}
{
bsl = MapView.Active.Map.GetLayersAsFlattenedList()
.OfType<BuildingSceneLayer>().FirstOrDefault();
var scenelayerName = bsl.Name;
}
System.Object
ArcGIS.Desktop.Framework.Contracts.PropertyChangedBase
ArcGIS.Desktop.Mapping.MapMember
ArcGIS.Desktop.Mapping.Layer
ArcGIS.Desktop.Mapping.CompositeLayer
ArcGIS.Desktop.Mapping.BuildingSceneLayer
Target Platforms: Windows 11 Home, Pro, Enterprise (64 bit)
